Safeguard Compass Pro
SAFEGUARD Compass Pro, Personal Voltage & Current Detector - Image 2

SAFEGUARD Compass Pro, Personal Voltage & Current Detector

Item Number: SGCE60-PRO Categories: , , , , Tags: ,

$ 337.88

SAFEGUARD COMPASS series devices are connected total emergency response solutions with advanced built-in voltage and current detection. When paired with the Safeguard Navigator Mobile App and Navigator Console, information about an injured worker’s condition and location is made available to your organization’s
emergency responders, reducing response times and communication errors. Internal sensors in COMPASS series automatically detect emergency events such as falls, impacts, and arc flashes. COMPASS series also has SOS capability and can detect and add no-movement information to emergency events.

  • Identify emergencies
  • Identify life conductors
  • Facilitate emergency response
Item in stock for fast shipping

Product Description

SAFEGUARD Compass Pro, Personal Voltage & Current Detector



User Guide download

Product Specifications

Weight .5 lbs
Shipping Dimensions 3 × 1.4 × .9 in
Power System

Rechargeable Lithium-Polymer (LiPo) Battery (3.7V, 250mAh).
Charging

1.5 hrs (USB 2.0 Micro B (5V) charger)
Directional Accuracy

Point source: Approximately ±20°
Detection Sensitivity

Eleven sensitivity levels + Smart Adaptive mode
Operating Conditions

-20°C to 60°C (-4°F to 140°F): DO NOT charge Compass if <0°C (32°F)
Detection Voltage Ranges

Low: 120VAC – 2.4kVAC
Medium: 2.4kVAC 34.5kVAC
High: 34kVAC – 500kVAC
Case Ratings

Flame Retardant: UL recognition 94V-0 at 1.5 mm
Electric Strength (IEC 60243-1): 34kV/mm
Electric Volume Resistivity (IEC 60093): 1.0E+ 14 ohms*m
