Greenlee Hard Metal Cutter 45mm

The Greenlee 45 mm Hard Metal Cutter is equipped with Bluetooth™ Communication enabled via the Greenlee Gator Eye app. Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback.

Designed specifically to cut ACSR, guy strand and ground rods State of the art 18V lithium-ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times Retraction Stop allows the operator to stop the ram retraction at any point simply by tapping the trigger, and then starting the next cutting cycle from that point, saving time and energy LED light provides the operator with the battery charge and tool maintenance status Two-stage hydraulic system provides fast advance and power speeds, saving time Forward handle position improves tool balance One trigger controls all tool functions Cutting head rotates 350° Tools automatically retract when the cutting cycle is complete Overmolded tacky grip areas make gripping the tool easier and more comfortable LED work light illuminates dark work areas Greenlee battery-powered cutting tools now use bio-degradable oil Smart Chargers control the charging current, charging voltage and battery temperature to maximize battery life Available with 120V, 12V or 230V battery charger or with 120V or 230V corded adapter in place of batteries and charger U.S. Patents #6,206,663 and #6,065,326

Contact us if you have any questions.

$3,719.98$3,733.28

Greenlee Hard Metal Cutter 45mm

  • Industry first shock-load damping system minimizes released energy
  • Quick-change field replaceable blade design minimizes down time
  • Equipped with double tap activation profile and electric motor stop to ensure no residual travel of blades
  • Flip-top style latch: compact and lighter design, ideal for one-handed overhead applications
  • Application and capacity identifiers: capacities are laser etched on tool with orange ring indicating hard metal cutting applications

GATOR Battery-powered In-line T/X Tools Service Manual

GATOR GATOR® Battery-powered In-line Cutters Instruction Manual

YouTube





Additional information

Weight 4.6 lbs
Dimensions 6.625 × 10 × 19 in
Type

Guillotine Style Cutter

Application

ACSR, Guy Strand, Steel

Handle Type

In-line style w/over-molded rubber grip

Cutting Edge

Hard Metal, Steel

Cutting Range

ACSR: 1590 KCMIL (MCM), (Falcon 54/19), Standard Guy Strand: 5/8 IN Diameter, EHS Guy Strand: 1/2 IN Diameter, Rebar (SCH 60): 1/2 IN Diameter, Wire Rope: 1/2 IN (13.000 MM)Cu, Wire Rope: 5/8 IN Diameter, Soft Steel Bolt: 3/4 IN Diameter

Jaw Size

1.77 IN (45mm)

Charger

120 VAC, 12 VDC

Brand

Greenlee
